TECNICAL FEATURES

METROLOGICAL FEATURES

• Rated capacity: (FS): 30 t, 40 t
• Combined error: 0,022 %F.S
• Creep error (after 30 min.): 0,14 %FS
• Temperature effect on zero: 0,02 %F.S./10°C
• Temperature effect on sensitivity: 0,01 %F.S./10°C
• Non-linearity error: 0,015%F.S.
• Non-repeatability error: 0,006%F.S.

OIML R60

• Vmin= Emax/18000
• Accuracy class: C4
• Max. number of intervals: 4000e (EC Test Certificate, according to OIML R60 (2000))

ELECTRONIC\MECHANICAL FEATURES

• Gas dischargers to protect against atmospheric discharges
• Double connector for load cells interconnection and weight indicator connection, without junction box.
• Halfduplex RS485 communication technology
• Rice Lake communication protocol
• Power Supply: 8…15 V (AC or DC)
• Rated digital output: 40000 d
• Current consumption: 35 mA
• Internal resolution: 24 bit
• Converter rate: max. 40 conv./sec.
• RS485 communication speed: Max 100kHz.
• Operating temperature: -35 ~ +70 °C
• Compensated temperature: -10 ~ +40 °C
• Storage temperature limits:: -40 ~ 80 °C
• Safe load limit: 150% F.S.
• Ultimate overload: 300% F.S.
• IP68 protection degree
• Stainless steel body
• 4-core RS485 cable as optional with stainless steel shield, diameter 7mm
• Self-centring spherical bases
• Equipped with anti-rotation system, to be combined with 173793 cups for proper operation
